Processor
• Dual Intel® 6th Gen Xeon® Birch Stream-SP，up to 144 cores each，max 350W • Support 6700P, 6500P, 6700E series CPU
Chipset
• None (Intel Xeon 6 PCH‑less architecture; all I/O provided by CPUs) • Xeon-6 SoC
|
Memory
• 32 × DDR5 slots ((RDIMM/3DS RDIMM)，up to 6400MT/s, 16 channels • 6700P, 6500P series CPU support MRDIMMs, up to 8000MT/s
Storage
• 2 x M.2-2280/22110 for NVMe PCIe 5.0 x4 • 2 x Rear hot-swap E1.S 9.5mm PCIe 5.0 x4 NVMe drive bays
|
Network
• 2 x 10GbE BaseT RJ45 LAN Ports from Intel® X710-AT2 • 1 x GbE dedicated for IPMI
Expansion Slot
• Front: 2 × PCIe 5.0 standard slots option；1 × OCP3.0 option, PCIe5.0 ×8 or ×16 , with NCSI • Rear: Up to 10 × PCIe 5.0 standard slots option； • 1 × OCP3.0 option, PCIe5.0 ×8 or ×16 option, with NCSI • Up to 3 × FHFLDW or 6 × FHFLSW or 8 × HHHLSW GPU
|
I/O
• 1 × Optional VGA(F) • 2 × USB3.0 • 1 × VGA • 2 × USB3.0 • 1 × IPMI RJ45 • 1 × COM • 1 × OCP NIC 3.0 slot option
|
Chassis
• 2U Rackmount with Front HDD LED • 6 x 2U Cooling Fans • Dimension: 3.43" H x 17.26" W x 25" D
|
Power Supply
• 2 x 2000W CRPS Platinum Level PSU
OS Support
• Windows Server, Linux, FreeBSD, VMware
|
Applications
• Virtual Server, Compute Server, Database Server, Cloud Computing
Environment
• System Operating Temperature: 0°C ~ 35°C • Non-operating Temperature: -20°C ~ 70°C • Non-operating Relative Humidity: 5% to 85% (non-condensing)
|
