Processor
• AMD EPYC™ 9005 series processors
Memory
• 12+12 x DIMM slots (1DPC) Supports DDR5 288-pin RDIMM, RDIMM-3DS • RDIMM: 96GB (2R) ,RDIMM-3DS: 512GB (2S8Rx4) • Up to 8TB ECC
|
Storage
• 16 x Hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays or 24 x Hot-swap 2.5" SATA/SAS* drive bays • *Additonal RAID/HBA card required to support the 24 x 2.5" SATA/SAS drive bays • 24-port NVMe/SATA/SAS* passive backplanes • *SAS drive is only supported with additonal RAID/HBA cards
GPU
• ASPEED AST2600 DDR4 512MB • Up to 10 x Dual-Slot NVIDIA RTX PRO™ 6000/5000/4500/4000, A100, H100, H100NVL, H200NVL, A800, H800 GPU cards via PCIe 5.0 x16 slots
|
Expansion Slot
• 10 x FHFL dual-slot PCIe5.0 x16 (with PEX89104 PCIe Switch) • 1 x FHFL single-slot PCIe5.0 x16 (CPU direct link) • Front: 2 x FHHL PCIe5.0 x16 • 2 x FHFL single-slot PCIe5.0 x8, shared space with adjacent dual-slot (with PEX89104 PCIe Switch)
Network
• Intel® i350: 2 RJ45 (1GbE) • 1 x OCP NIC 3.0 (PCIe5.0 x16)
|
I/O
• 1 × VGA • 2 Type-A (USB3.2 Gen1) • 2 × IPMI RJ45 • 1 × Standard OCP NIC 3.0 slot
Internal I/O
• 2 × USB 3.2 header • 1 × VROC Key header • 12 × 4pin FAN • 1 × COM header • 1 × VGA header for FP • 1 × SPI TPM 2.0
|
Front Panel
• 2 x RJ45 (1GbE) by Intel i350, shares with Rear IO • 1 x dedicated IPMI, shares with Rear IO • 4 x Type-A (USB3.2 Gen1) • 1 x DB15 (VGA)
Chassis
4U Rackmount
• Dimensions: 786 x 438 x 176.5 mm (30.9'' x 17.2'' x 6.9'')
|
Power Supply
• 4 x Standard CRPS Power Modules，hot-swappable, support 2+2/ 3+1/ 1+1 redundancy • 1600W/2000W/2400W/2700W Platinum or Titanium power supply module optional
OS Support
Windows Server, Linux
|
Applications
• GPU for AI, Deep Learning, HPC.
Environment
• Operating Temperature: +10 to +35 C • Non-operating Temperature: -40 to +70 C • Operating Relative Humidity: 10% to 80% (non-condensing) • Non-operating Relative Humidity: 10% to 93% (non-condensing) • MTBF: 100,000 Hours • FCC, CE, UL, RoHS Compliance
|
