Processor
|
• Intel® Xeon™ Processor E5-2600 V4 Series |
Memory
|
• 32GB Quad-Channel ECC DDR4 system memory• Optional: up to 2 TB system memory |
OS and Storage Manager
|
• Linux OS and NAS/iSCSI WEB based Manager• Optional: Red Hat Ceph,Solaris, Windows Server, MS Storage Server, VMware, FreeBSD, Other Open Soruce Linux. |
File System
|
• XFS, EXT3 standard
• Optional: ZFS, NTFS, or any file system supported by the x86 platform
|
Network I/O
|
• Optional: Additional 4 or 8 Gigabit LAN, 10Gbit Ethernet, Fibre Channel for SAN (can be mixed) • 56Gbit FDR or 40Gbit QDR Infiniband supported |
Network Service
|
• DHCP client/server (default is DHCP client/static) • Network Protocol: CIFS/SMB, NFS, FTP • iSCSI / NAS / SAN (Can be mixed) |
Management Interface
|
• Web GUI • E-mail notification • Local Host Access via VGA and Keyboard |
Expansion Slot
|
• Up to 6 x PCIe 3.0 slots (full height, full length)
|
Remote Boot Function
|
• Requires NIC with PXE support on client
|
File Sharing
|
• Authorizes users to access shared folder using passwords (by default, there is one "Public" shared folder) |
Access Control
|
• Allows users to access shared files for "Read Only" or "Read/Write" |
Storage/RAID
|
• Hardware accelerated RAID controller (3 RAID processors) PCIe 3.0 8x bus • Up to 2,000MB/sec sustained read and write. Unparalleled performance • Over 8,000MB/sec random write and 3,500MB/sec random read • 74 x 3.5" hot-swap drive bays for SAS/SATA• Optional: 1 Internal 3.5" and 2 x 2.5" drives • RAID 0, 1, 1E, 3, 5, 6, 10, 30, 50, 60 with hot spare support (mixed configurations available) |
I/O Ports
|
• 4x USB 2.0 rear connectors • 2 x USB 3.0 Front Connectors • VGA graphics • 2 x LAN Port (Optional : 4 Lan) • 1 x Serial COM rear • 2 x SATA-6G/s, 4 SATA-3G/s SATA port, optional SAS ports supported • Optional: 2 additional I/O (such as PS/2, TPM) supported by header or add-on |
Client Support
|
• MS Windows® 8, 7, XP and Windows Server, Linux , FreeBSD, Solaris and Mac • Snap Shot Backup and Recovery Client Support • Active Directory, Rsync are supported |
Remote Controls
|
• Power on/off, system reset + USB • IPMI, KVM over IP, Remote Power On/Off is supported |
Indicators
|
• Power, LAN and HDD LEDs |
Cooling
|
• Rear: 9 x 40 x 56mm hot-swap fans for HDD Bays + 4 x 60 x 38mm fans for MB |
Power Supply
|
• 1350W 3+1 redundant power supply (4 x 500W modules) UR/FCC/CE Certified |
Operating Temperature
|
• From 0 ºC to 40 ºC (32ºF to 104 ºF) |
Non-Operating Temperature
|
• From 0 ºC to 40 ºC (32ºF to 104 ºF) |
Operating Humidity
|
• From 10% to 90% relative humidity |
EMI Safety
|
• CE/FCC |
Dimensions
|
• 8U Rackmount Chassis
• Dimensions: 19" W x 14" H x 27" D
• Weight: 200 lb.
|
Warranty
|
• SAS and SATA-E Hard Driver carry 5 year,SATA-N carries 3 year • Base system:3 year standard parts and depot labor;lifetime toll free phone support. • Optional:3 or 5-year(total years) extended warranty with advanced parts replacement service.• Optional:7+year extended warranty service available. • On-site service is available with additional cost. |
