Processor
• Intel® 9th/8th Generation Coffee Lake processor • LGA1151 socket series with 35W, 65W to 95W TDP • Intel® Core™ i9-9900K, 9900, 9900T 8C/16T series 16M Cache • Intel® Core™ i7-9700, 9700T, 8700, 8700T series 6C/12T 12M Cache • Intel® Core™ i5-9600, 9500, 9400T, 8400, 8400T series 6C/6T 9M Cache • Intel® Core™ i3-9300, 9100, 9100T, 8100, 8100T series 4C/4T 6M Cache • Intel® Pentium® Gold G5600 series 2C/4T 4M and Celeron® G4900 series 2C/2T 2M
Chipset
• Intel® H310 Express Chipset • Option: Intel® Q370 Express vPro® Technology
|
Graphics
• Intel® UHD 630 Graphics, 4K Resolution, HDR 10Bit color • Support 2 Graphics ports • 1 x HDMI® , supporting a maximum resolution of 3840x2160 30Hz Support for HDMI® 1.4 version and HDCP 2.2 • 1 x DP 4K 60Hz Graphics port • 1 x VGA header
Memory
• 2 x DDR4 SO-DIMM
• 2666/2400/2133MHz unbuffered non-ECC (Dual Channel I/O)
• Supports up to 64GB (however 32GB is most practical)
|
Network
• 2 x Intel® I211 Gigabit (10/100/1000 Mb/s) LAN • 1 x M.2 2230 socket (Taken by WiFi+BT Module) • Wake on LAN, PXE boot (Diskless) supported • Option: additional Gigabit LAN can be added by USB LAN module
Expansion Slot
• 1 x PCI Express 3.0 x slot • 1 x M.2 2230 (for WiFi+BT or Other Module)
|
Storage
• 2 x SATA 6Gb/s • 1 x mSATA 6Gb/s
Audio
• Realtek® ALC662 6-channel (5.1) • Internal audio, S/PDIF headers • 1 x 3.5mm Analog Stereo Audio jack
|
Back Panel I/O
• 2 x USB 3.0 ports • 4 x USB 2.0 ports • 1 x HDMI® port • 1 x DP • 2 x LAN ports • 1 x 3.5mm Audio jack • 1 x DC-In 2.5mm Power Connector
Internal I/O
• 2 x USB 2.0 headers • 2 x Serial COM headers • 1 x VGA header • 1 x S/PDIF header
|
Other I/O
• 2 x USB 3.0 ports (Front)
Function
• 1 x TPM header
|
System BIOS
• AMI® UEFI 64MBit BIOS
• Watchdog supported
|
Chassis
• 138D Small Form Factor with aluminum panel, Convertible to 1U Rackmount • Dimensions: 7"(W) x 7.2"(D) x 1.38"(H), Weight: 3 lb (Net) 10 lb (gross with packaging) • Cooling: Slim CPU Fan with Heatsink • Color: Black as default color, option: Gun Grey, Silver, Gold. Other custom color available • Supports VESA, wall mount or rackmount brackets • Option: 100F Fanless 1.4" Slim • Option: 400R with RISER Slot 400S Swap Bay 2x2.5" • Option: 1750C with slot • Option: 1750F Fanless with slot • Option: 236F3 Fanless
Power Supply
• Power: DC12V or DC19V 60W or higher wattage Power Adapter 2.5mm plug (UL/CE/FCC Certified) • Power Cord: Standard US Power Cord included, European Power Cord available as option • Energy Star Compliance, Idle mode at <1W
|
OS Support
• Stratodesk NoTouch OS
Application
• Set Top Box, Network Appliance, Digital Signage, POS/Kiosk, Surveillance, IP/PBX, IoT/Edge System, etc.
• Embedded-Longevity
|
Environment
• Operating Temperature: 0 to +55 C
• Non operating temperature: -20 to +70 C
• Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz
• Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz
• Shock - Operating: 3,920 m/s2 (400G) 2ms
• Shock - Non-Operating: 8,820 m/s2 (900G) 1ms
• Operating Relative Humidity: 8% to 90% (non-condensing)
• Non-operating Relative Humidity: 5% to 95% (non-condensing)
• MTBF: 100,000 Hours
• RoHS Compliance
|
