Processor
• Dual Sockets Intel® 4th / 5th Gen Xeon® Sapphire Rapids/ Emerald Rapids, up to 350W
|
Memory
• 32× DDR5 slots (RDIMM)，16-channel (8-channel per CPU), up to 5600MHz, supports RDIMM/3DS RDIMM • Up to 8TB ECC
Storage
• Up to Front 24 x 2.5" SAS/SATA (4 can be for NVMe U.2) or 12× 3.5” SAS/SATA Drives • 2× M.2-2280/22110 PCIe 4.0 4x NVMe SSD for OS Boot Drives (supports RAID-1 Mirror)
|
GPU
• Up to10 NVIDIA® Dual-Slot RTX PRO™ 6000/5000/4500/4000, A100, H100, H100NVL, H200NVL, A800, H800 GPU cards via PCIe 5.0 x16 Slots
Expansion Slot
• Up to 15 × standard expansion slots • Up to 10 × FHFL GPU cards (8-cards is optimal) • Supports 5 × PCIe5.0 16x + 2 × PCIe4.0 8x (in addition to 8 GPUs)
|
Network
• Supports 1×OCP3.0 expansion slot standard with PCIe 5.0 x8, (x16 is optional) • LAN options: 4×1GbE / 2×10Gb SFP+ / 4×10Gb SFP+/ 2×25Gb SFP28 • Supports NCSI
I/O
• 1 × VGA • 1 × COM • 2 × USB3.0 • 1 × IPMI RJ45 • 1 × Standard OCP NIC 3.0 slot
|
Front Panel
• 2×USB3.0 • 1×Optional VGA
Internal I/O
• 2 × USB 3.0 header、2 × USB 2.0 header、1 × USB 2.0 Type A • 1 × VROC Key header • 12 × SATA 3.0 (3 × SFF-8643), supports RAID 0, 1, 5, 10 • 3 × MCIO (PCIe 5.0x8), supports 6 × NVMe（PCIe 5.0 x 4） • 2 × M.2 , PCIe 4.0 x4 , 2280 & 22110 • 12 × 4pin FAN • 1 × VGA header for FP • 1 × SPI TPM 2.0
|
OS Support
Windows Server, Linux
Chassis
4U 19" Standard Rackmount
• 2.5” Configuration: W 448mm × H 175mm × D 772mm （792mm with ear bezel） • 3.5” Configuration: W 448mm × H 175mm × D 822mm （842mm with ear bezel）
|
Application
• GPU for AI, Deep Learning, HPC.
Power Supply
• 4 × Standard CRPS Power Modules，hot-swappable, supports 2+2/ 3+1/ 1+1 redundancy • 1600W/2000W/2400W/2700W Platinum or Titanium power supply module optional
|
Environment
• Operating Temperature: +10 to +35 C • Non-operating Temperature: -40 to +70 C • Operating Relative Humidity: 10% to 80% (non-condensing) • Non-operating Relative Humidity: 10% to 93% (non-condensing) • MTBF: 100,000 Hours • FCC, CE, UL, RoHS Compliance
|
