Processor
• Intel® Core™ Ultra X9 388H vPro 2.1/5.1GHz 16C Arc B390 18M 25/80W • Intel® Core™ Ultra 9 386H vPro 2.1/4.9GHz 16C Intel GPU 18M 25/80W • Intel® Core™ Ultra X7 368H vPro 2.0/5.0GHz 16C Arc B390 18M 25/80W • Intel® Core™ Ultra 7 366H vPro 2.0/4.8GHz 16C Intel GPU 18M 25/80W • Intel® Core™ Ultra 7 355 2.3/4.7GHz 8C Intel GPU 12M 12/25/55W • Intel® Core™ Ultra 5 338H vPro 1.9/4.7GHz 12C Arc B370 18M 25/65W • Intel® Core™ Ultra 5 336H vPro 1.9/4.6GHz 12C Intel GPU 18M 25/65W • Intel® Core™ Ultra 5 322 2.5/4.4GHz 6C Intel GPU 12M 12/25/55W
Chipset
• Intel® Panther Lake Platform (SOC)
|
Graphics
• Intel® Arc® B390/B370/UHD Graphics Processor • Support 4 Display, Optional 1 or 2 HDMI-in • 4 x HDMI 2.1 8K 60Hz • 1 HDMI-in 4K 60Hz, Optional up to 2 HDMI-in (Based on CPU with IPU) • Option: 1 DP + 3 HDMI or 4 DP (as special order, MOQ required)
Memory
• 2 x DDR5 SO-DIMM, up to 128GB • 7200/6400/5600/4800MHz unbuffered non-ECC (Dual Channel I/O)
|
Network
• 1 x Realtek® RTL8125 2.5Gigabit (10/100/1000/2500 Mb/s) Ethernet • 1 x Intel® i219LM Gigabit (10/100/1000 Mb/s) vPro supported • 1 x M.2 2230 (for Wi-Fi 4/5/6/7 + BT or Other Module) • 1 x M.2 3042/3052 (for 5G/4G-LTE Module Pair with SIM Card) • Additional NIC by M.2 or PCIe modules • Wake on LAN, PXE boot (Diskless) supported
Expansion Slot
• 1 x PCIe 4.0 x4 Slot (with RISER for low profile half-length card) • 1 x Optional PCIe 4.0/3.0 x8 Slot (Require special Chassis) • 1 x M.2-2280 PCIe 5.0 4x for NVMe/SATA SSD • 1 x M.2 2230 (for Wi-Fi + BT or Other Module) • 1 x M.2 3042/3052 (for 5G/4G-LTE Module Pair with SIM Card)
|
Storage
• 1 x M.2 2280 (for SATA-6GB/s or PCIe x4 NVMe) • Additional storage through two PCIe expansion cards
Audio
• Realtek® ALC897 HD 8-channel (7.1) • 2 x 3.5mm Analog Stereo Audio jacks • Digital HD Audio through HDMI port
|
Back Panel I/O
• 1 x Type-C USB 3.2 Type-C (10Gb) • 4 x HDMI 2.1 + 1 x HDMI-in • 2 x RJ45 LAN ports • 1 x 5pin Phoenix Serial port • 1 x DC-In 2.5mm Power Connector
Other I/O
• 4 x USB 3.2 Ports (Front) • 2 x 3.5mm Audio in/Out jack (Front) • 1 x Power Button (with Power LED indicator) • 1 x Reset or Test Button (Front)
|
Internal I/O
• 2 x 10pin USB Headers for 4 USB 2.0 Ports
Function
• 1 x TPM Header (for Infineon TPM 2.0 module)
|
System BIOS
• AMI® UEFI 128MBit BIOS • Watchdog supported
Chassis
• Boo-size Chassis with Copper Heat-pipe blower fan for Cooling • Dimension: 8” (W) x 7.16” (D) x 1.65” (H) • Net Weight: 3lb (net) 6lb (gross with packaging) • Color: Black (other color and custom logo are available with MOQ orders) • Supports VESA/wall-mount, mini-1U Tray (order separately) Fits two units in single 1U Tray for fail over configurations
|
Power Supply
• Power: DC12V or DC19V 60W-120W Power Adapter 2.5mm plug (UL/CE/FCC Certified) Optional with Lock • Power Cord: Standard US Power Cord included, European Power Cord available as option • Energy Star Compliance, Idle mode at <1W
OS Support
• Windows 11, IoT, Linux
|
Applications
• Audio/Video Encoding/Decoding Appliance, Videowall, Network Security, Kiosk, Edge AI, Visual Computing, IoT, etc.
Environment
• Operating Temperature: -20 to +40C (Optional 60c) • Non-operating temperature: -20 to +70 C • Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz • Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz • Shock - Operating: 3,920 m/s2 (400G) 2ms • Shock - Non-Operating: 8,820 m/s2 (900G) 1ms • Operating Relative Humidity: 8% to 90% (non-condensing) • Non-operating Relative Humidity: 5% to 95% (non-condensing) • MTBF: 100,000 Hours • FCC, CE, RoHS Certified
|
