i5-4200FL

Intel® Core™ i5-4200u, 1 HDMI+1 VGA, 2 SATA, 1 mSATA

Featured Highlights
	Intel® Core™ i5-4200u Processor
	Intel® Haswell Platform (SOC)
	Intel® HD 4600/5000 Series Graphics, 4K Display, 1 HDMI+1 VGA
	2 x DDR3L SO-DIMM for up to 16GB Memory
	2 x MiniPCIe slots
	1 Realtek® Gigabit LAN
	4 USB 3.0, 1 USB 2.0
	2 x SATA, 1 x mSATA
	5.1 ALC662 Audio Sound
	Power Supply: DC12V input
	OS Support: Windows 7 32-bit, Windows 7 64-bit, Windows 8x, Windows 10 64-bit, Linux
	Applications: Digital Signage, Media Player/IPTV, etc.

SKU: i5-4200FL

Specifications
Request for Info

Product specifications

Processor • Intel® Core® i5-4200u 1.60/2.60GHz 2Core 4Threads 3M 15W Chipset • Intel® Haswell Platform (SOC)
Graphics • Intel® HD 4600/5000 Series Graphics, 4K Display • Support 2 Graphics ports • 1 x HDMI® Port • 1 x VGA Port Memory • 2 x DDR3L SO-DIMM • 1600/1333MHz unbufferred non-ECC (Dual Channel I/O) • Supports up to 16GB
Network • 1 x Realtek® Gigabit (10/100/1000 Mb/s) LAN • Wake on LAN, PXE boot (Diskless) supported • Optional WiFi via miniPCIe module • Option: additional Gigabit or 10Gbit LAN can be added via PCIe slot or by USB LAN module Expansion Slot • 2 x MiniPCIe sockets (supports WiFi+BT or mSATA)
Storage • 2 x SATA 6Gb/s • 1 x mSATA 6Gb/s Audio • Realtek® ALC662 6-channel (5.1)
Back Panel I/O • 4 x USB 3.0 Ports • 1 x HDMI® port • 1 x VGA port • 1 x LAN port • Optional 2 RS-232 via USB to Serial module Internal I/O • 1 x USB 2.0 Header
Chassis • 300 Series Fanless Aluminum Chassis • Dimensions:300 Case: 8.1(L) x 8.1(W) x 2.2(H) inch • Drive Bay: One 2.5" HD/Solid State Drive Bay • Optional PCIe 1x RISER + MiniPCIe + mSATA slots + Slim DVD or Bluray optical drive • System Weight: 3.9 lb(Net) and 6 lb(Gross with packaging) • Color: Black as default color, custom colors available with special order • Supports VESA, wall mount or rackmount brackets • 300B Aluminum 2.1" H 300A w/Slim DVD Bay 300R with RISER Slot • Optional: 175C Case 1.75" H 175F Fanless 1.75" H Power Supply • Power: DC12V Power Adapter (UL/CE/FCC Certified) • Power Cord: Standard US Power Cord included, European Power Cord available as option • Energy Star Compliance, Idle mode at <1W
OS Support • Windows 7 32-bit, Windows 7 64-bit, Windows 8x, Windows 10 64-bit, Linux Applications • Digital Signage, Media Player/IPTV, etc.
Environment • Operating Temperature: 0 to +55 C • Non operating temperature: -20 to +70 C • Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz • Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz • Shock - Operating: 3,920 m/s2 (400G) 2ms • Shock - Non-Operating: 8,820 m/s2 (900G) 1ms • Operating Relative Humidity: 8% to 90% (non-condensing) • Non-operating Relative Humidity: 5% to 95% (non-condensing) • MTBF: 100,000 Hours • RoHS Compliance
