Nano-UC14L6 - Intel® Core™ Ultra Processors (Series 1) Meteor Lake Quad LAN Mini-PC

Chipset

• Intel® Meteor Lake Platform (SOC)

Memory

• 2 x DDR5 SO-DIMM
• 5600/3200/2666MHz unbuffered non-ECC (Dual Channel I/O)
• Supports up to 96GB

Expansion Slot

• 1 x M.2 2230 E Key for WiFi/BT (CNVi only)
• 1 x M.2 3042/3052 B Key or 5G/4G with SIM
• 1 x Mini-PCle slot for 4G/3G with SIM
• 1 x PCle x8 Expansional Slot for Optional 2 or 4*SPF+ Ports

Back Panel I/O

• 4 x USB 2.0 ports
• 2 x USB3.2 ports
• 1 x HDMI® 2.1 ports
• 1 x DP 2.1
• 1 x Type C
• 6 x LAN ports
• 1 x 4G slot, 1 x 5G slot,
• 1 x power switch

Function

• Power-on-boot, scheduled power-on, Wake-on-LAN, PXE boot

Chassis

• Nano Chassis  7.6"(W) x 4.90"(D) x 2.1"(H)   2.75 lb. (net) 6 lb. (gross)
• Color: Black or Silver as default color, custom colors available with special order
• Supports VESA, DIN, wall mount or rackmount brackets

OS Support

• Windows 11/10, IoT, Linux, FreeBSD

Environment • Operating Temperature: -5~-20 to +40~+60 C (Please contact product specialist for details)• Non operating temperature: -20 to 70 C• Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz• Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz• Shock - Operating: 3,920 m/s2 (400G) 2ms• Shock - Non-Operating: 8,820 m/s2 (900G) 1ms• Operating Relative Humidity: 8% to 90% (non-condensing)• Non-operating Relative Humidity: 5% to 95% (non-condensing)• MTBF: 100,000 Hours• FCC, CE, RoHS Certified
